Model HZSA

Model : HZSA
Standards: API 610, ISO 5199

Model HZSA is a single or multi-stage centrifugal pump with shaft seal and gas delivery stage.

The gas conveyor operates on the principle of a side channel pump. In gas production, a return of the gas is achieved in the liquid phase by increasing the pressure in the side channel stage.

To achieve very low NPSH values, the suction stand is designed with an axial inlet and the suction side impeller with an enlarged inlet cross section.

The axial thrust compensation takes place through relief boreholes and throttle gaps, wear rings are standard on the suction and pressure sides. The pump shaft is mounted in a double-row angular contact ball bearing and SiC plain bearings.

Feature

• Q max: 600 m³/h [2640 g.p.m.]**

• H max: 500 m [1640 ft]**

• operating pressure: 16 bar [232 psi]*

• temperature: 100° C [212° F]*

• max rotational speed: 3500 min−1

• gasket/mechanical seal: mechanical seal

• installation: horizontal

• self-priming: yes

• bearing: rolling bearing, plain bearing, product side plain bearing

• lubrication: grease

• materials: austenitic steel

• standards: API 610, ISO 5199

• explosion protection: category 2 / zone 1
