Positive Displacement Flowmeters – Small capacity flowmeters
BanksiaControls small capacity flowmeters provide precise volumetric measurement of small quantities of liquids or low flows found in a broad range of industrial & commercial industries including automotive, aviation, mining, power, chemical, pharmaceutical, food, paint, medical engineering, petroleum & environmental. Applications include additives for fuel, consumer products, water treatment, flotation cells & de-foaming plants, corrosion inhibitors, perfumes, catalysts, emulsifiers, oils, grease, glues, ink & insecticides.
GENERAL SPECIFICATIONS* :
- flow range : 0.5~550 litres/hr (0.16~145 USGPH)
- nominal sizes : 4~8mm ( 1/8”~3/8” )
- linearity : +/-1% of reading
- repeatability : +/-0.03% repeatability
- temperature : – 20~+120ºC (-4~250ºF)
- materials : 316 stainless or aluminum
- pulse outputs : reed switch & NPN open collector (standard)
STANDARD OPTIONS :
- LCD totaliser
- LCD flow rate totaliser
- LCD two stage batch controller
- Optional Exd I/IIB/IIC approval (ATEX, IECEx) or Ex ia (Simple Apparatus)
- 4~20mA, scaled pulse & alarm outputs
- Quadrature pulse output
