Model NMT

Model: NMT
Standard: DIN EN ISO 2858, ISO 15783

Model NMT is a volute casing submersible pump with shaft seal according to the principle of the two-pipe pump, i. e. separate shaft sealing pipe and pressure pipe. The hydraulic pump part is arranged in the container or in the pumped medium.

The connection is made by a multi-level shaft and pipe string. With the NMT, submersible length of up to 6 meters are possible with a flow rate of up to 1000 m³/h [4400 gpm].

The pump has a permanent magnet coupling, and the containment shell hermetically seals the fluid to the outside. The direct mounting of the drive motor eliminates additional bearings and the mechanical coupling.

Feature

• Q max: 1000 m³/h [4400 g.p.m.]**

• H max: 250 m [820 ft]**

• operating pressure: 16 bar [232 psi]*

• temperature: 200° C [392° F]*

• max rotational speed: 3500 rpm

• gasket/mechanical seal: magnetic coupling

• installation: vertical, submersible pump

• self-priming: no

• bearing: plain bearing

• lubrication: grease

• materials: duplex, Ni-based, spheroidal graphite iron / cast steel, austenitic steel

• standards: DIN EN ISO 2858, ISO 15783

• explosion protection: category 1 / zone 0
