HTV Self-Regulating Heating Cable

Raychem HTV self-regulating heating cable is designed for freeze protection or process temperature maintenance of pipes and vessels up to 205°C continuously, with a maximum exposure temperature of 260°C. The HTV cable has a solid construction with a high power retention (HPR) heating core and pressure extruded electrical insulation. It is then integrated with a robust metallic braid and a chemically resistant fluoropolymer outer jacket.

Features

High power retention (HPR) heating core
Power retention: At least 95% after 10 years
Design life: 30 years or more depending on application
Simplified design in hazardous area: T3 and T2
Longer circuit lengths due to larger cross section conductors
Fast installation: cut-to-length, multiple overlaps allowed, meter markings, user-friendly connections kits
